OWNER ACCOUNT

Device Name

Customize the device name under your account. 1–50 characters.

SD Card

WUUK Baby Monitor supports a Micro SD card up to 256 GB (Micro SD card not included in the package)
WUUK Baby Monitor using the SD card with the Format FAT32. After plugging the SD card into the camera, kindly go to the doorbell settings to check the SD card status.
-If the option shows "Action Required", you can just simply tap the option to format the SD card into FAT32 directly.
-If it shows "No Card", the SD card might be defective to be recognized or there is no card.
Note：Please complete the pairing process before plugging the SD card into the camera.

Recording Mode

Continuous Recording: It supports 24/7 Live Stream & Recording.
Event Only: The camera will be triggered by movements/humans to record a video.

Cloud Service

Toggle on/off the cloud service, which represents whether the event recording of this baby camera will be uploaded and saved onto WUUK Cloud.
Note: WUUK provides a 1-month trial at no cost for Cloud service. Please go to wuuklabs.com, select Advanced Service and log in to your WUUK account to subscribe to the cloud service.

Watermark And Time Format

Choose to display (or not) the WUUK brand logo/timestamp, as well as choose the time format to be displayed.

Wi-Fi

Displays the Wi-Fi info to which the baby camera is connecting. The Cam supports 2.4Ghz Wi-Fi only.

Motion

Motion Detection: When this feature is enabled, the camera will be triggered to record the videos when moving objects or humans are detected.
Detection Sensibility: The sensitivity level is from Low/ Medium/High. The higher the sensitivity is, the more efficient the motion detection is.
Detection Zone: Determine the detection rage by adding an editing new zone. Only motion within those zones will trigger event recording. Tap to select the region you want to adjust, touch the points to move the zone or adjust the area range, and save the change. Up to 5 zones can be added.

Sound

Recording Sound: There will be no sound in the recorded videos after this feature is disabled.
Sound Detection: When this feature is enabled, the camera will be triggered when there is sound.
Detection Sensibility: The sensitivity level is from Low/ Medium/High. The higher the sensitivity is, the more efficient the sound detection is.

Temperature and Humidity

Temperature unit: Select temperature control unit
Out of Range Alert: If the temperature and humidity exceed the set range, the camera will send a notification.
Temperature Range: The highest value needs to be set first.
Humidity Range: The highest value needs to be set first.

Notification

Motion notification: Notify motion activities
Sound Notification: Notify sound
Notification sound: Choose your favorite ringtone (4 options).

Privacy Mode

Enabling this feature will cause the camera lens to rotate to the top position, rendering the main functions of the camera unavailable.

Indicator Light

If this option is disabled, the LED light on the device will be turned off, but the recording feature won't be affected.

Screen Flip

If the option is turned on, the screen will be flipped by 180°.

Firmware Update

After updating the firmware, it will restart automatically.

Night Vision

Auto: The infrared lights will be on at night under the event recording or live view. The camera switches to black and white night vision at night.
On: The infrared lights will keep on all the time under the event recording or live view. The camera images remain in black and white.
Off: The infrared lights will keep off all the time.

Time Zone

Switch to the correct time zone according to your location, remember not to forget to click Save.

User Management

If you want to share the device, please select Add a User, enter his WUUK account, and send him an invitation. You can choose to add or remove the shared account.

Network Diagnosis

Each diagnosis only represents the current device status.
WUUK Server: Check whether your phone has internet so far
Device Connection: Check whether the camera is connecting to the router.
Device Signal: Show the connection signal strength. The greater the value tested, the stronger the signal is.

Reboot Device

Remote reboot the device.

About Device

Show model number BA530, your personal SN number and MAC address.
When you encounter any problems with the device, usually the SN info is provided as very important information to the support team, which can quickly solve your problem.

Remove Device

To delete this camera from your WUUK account.
